A Comprehensive Analysis of Common Specifications of Truck Cover Fabrics

2025-04-30 17:05:22 Chaoshida Special Textile

In the field of truck transportation, truck cover fabric is a key element in ensuring the safety of goods and resisting wind and rain. Its importance is self-evident. Reasonable selection of cover fabrics is not only related to the efficient operation of the transportation process, but also has a far-reaching impact on extending the service life and improving economic benefits. In view of this, in-depth discussion of the specifications of truck cover fabrics has become the focus of industry attention. This article will systematically analyze this topic and present you with a comprehensive and professional analysis!

1. Thickness

The thickness of truck cover fabrics is often measured in millimeters (mm) or ounces (oz). Common specifications include:

  • 0.3mm~0.6mm: suitable for short-distance transportation or light goods

  • 0.7mm~1.2mm: suitable for daily protection of medium and heavy goods

  • 1.5mm and above: used in special protection scenarios, such as heavy machinery and construction material transportation

The higher the thickness, the stronger the waterproofness and tear resistance, but the weight and cost will also increase accordingly.

truck-cover-fabric

2. Gram weight (GSM, Grams per Square Meter)

Gram weight represents the weight of fabric per unit area and is an important parameter for measuring fabric density and thickness:

  • 300~500 GSM: lightweight, suitable for temporary covering or short-term use

  • 550~700 GSM: standard, widely used in medium and large trucks

  • 800 GSM and above: heavy-duty, often used for high-load transportation or extreme climate conditions

3. Material type

Truck cover cloth is usually made of the following materials:

  • PVC-coated polyester cloth: waterproof, UV-resistant, wear-resistant, suitable for long-distance transportation

  • PE (polyethylene) woven cloth: light, economical, suitable for light transportation and dust and rain protection

  • Canvas (waxed or glued): good air permeability, suitable for transporting agricultural products, wood and other goods that require breathable packaging

  • Composite materials: such as PVC + polyester composite, combining strength and weather resistance

4. Size and customization range

Common truck cover cloth sizes:

  • Width: 1.8 meters ~ 4 meters (can be spliced)

  • Length: Customizable on demand, up to 20 meters

  • Edge technology: edging, thickening, tear-proof treatment

Most manufacturers support customized sizes, shapes, and colors to meet the needs of different models and goods.

5. Tensile strength and tear resistance

These two indicators are directly related to the service life of the cover in the wind and sun:

  • Tensile strength: usually greater than 800N/5cm, can withstand strong pulling in strong winds or high-speed driving

  • Tear strength: higher than 100N, prevent small holes from expanding and extend the service life

truck-cover fabric

6. Other key performance parameters

ParameterDescription and standard range
Waterproof levelUsually IPX4~IPX6, impermeable in strong rain
Temperature range-30℃ to 70℃, adapt to extreme climate environments
Flame retardant levelOptional NFPA701, DIN4102 standards
UV resistance≥ 500 hours of UV resistance, delaying aging
Color optionsCommon blue, green, gray, and black, can also be customized

7. Application suggestions and selection reference

Use scenarioRecommended thickness/GSMRecommended material
General daily transportation500~600GSMPVC-coated cloth
Heavy machinery transportation800GSM or aboveThick PVC or canvas
Agricultural product transportation400~500GSMwaxed canvas
Temporary cover/dustproof300~400GSMPE woven fabric

Summary: Choose the right specifications to use it with more peace of mind!

Whether it is short-distance transportation or long-distance inter-provincial transportation, choosing the appropriate Truck Cover Fabric specifications can significantly improve the protection effect, reduce the frequency of replacement, and save operating costs. In actual purchase, it is recommended to conduct a comprehensive assessment based on the use environment, cargo properties and budget requirements, and choose customized services when necessary to obtain the best adaptation solution.
